USS HARPERS FERRY LSD-49 (CV) SHIP’S LOADING CHARACTERISTICS PAMPHLET

---

2nd Deck (Aft)
                                  A. Marine Embarkation Work Center - 2-126-2-Q
                                  B. Troop Ammunition Magazine #4 (White Phosphorus) (under ramp) - 1-78-2-M
                                  C. Laundry Receiving & Issue - 2-115-1-Q
                                  D. Troop Cargo Storeroom - 4-81-0-A


Drawing not to scale. Refer to CAEMS for scale loading diagrams


II-12
